CCTV Cameras / Eyeball Cameras / Network Cameras / Security Cameras
SKU: IPC-HDW4431EM-AS
Dahua IPC-HDW4431EM-AS is a 4MP IR eyeball network camera designed for dependable indoor and outdoor video surveillance. It combines high resolution imaging with efficient compression, helping users capture detailed footage while reducing bandwidth and storage demands.
This camera is built for practical security installations where consistent image quality and straightforward deployment matter. The integrated microphone adds audio capture, while infrared illumination supports monitoring in low light and night conditions.
Its weather resistant housing and PoE capability make it well suited for professional CCTV systems in homes, commercial premises, and general perimeter coverage. Dahua positions this model as a compact fixed lens network camera that balances image performance, durability, and installation flexibility.
| Model | IPC-HDW4431EM-AS |
|---|---|
| Product Type | IR Eyeball Network Camera |
| Image Sensor | 1/3” 4Megapixel progressive scan CMOS |
| Effective Pixels | 2688(H) x 1520(V) |
| RAM/ROM | 512MB/32MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | 1/3(4) to 1/100000s, Auto/Manual |
| Minimum Illumination | 30IRE, 0.06Lux/F1.6 (Color, 0.4Lux/F1.6 (Color, 0Lux/F1.6 (IR on), 1/30s, 1/3s |
| S/N Ratio | More than 50dB |
| IR Distance | Up to 50m (164ft) |
| IR On/Off Control | Auto/Manual |
| IR LEDs | 1 |
| Lens Type | Fixed |
| Mount Type | Board-in |
| Focal Length | 2.8mm |
| Optional Lens Sizes | 3.6mm, 6mm |
| Max. Aperture | F1.6 |
| Angle of View | H:104°, V:58° |
| Close Focus Distance | 1.1m |
| DORI Distance 2.8 mm | Identify 6m, Detect 56m, Observe 22m, Recognize 11m |
| Pan/Tilt/Rotation Range | Pan: 0° to 360°, Rotation: 0° to 360°, Tilt: 0° to 78° |
| IVS | Intrusion, Tripwire, Object Abandoned/Missing |
| Advanced Intelligent Functions | Face Detection |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Streaming Capability | 3 Streams |
| Resolution | 1.3M (1280×960), 1080p (1920×1080), 3M (2304×1296), 4M (2688×1520), 720p (1280×720), CIF (352×288/352×240), D1 (704×576/704×480), VGA (640×480) |
| Frame Rate, Main Stream | 4M (1 to 25/30fps) |
| Frame Rate, Sub Stream | D1 (1 to 25/30fps) |
| WDR | 120dB |
| Day/Night | ICR |
| 3D NR | Supported |
| AWB | Supported |
| AGC | Supported |
| BLC | Supported |
| Smart IR | Supported |
| Digital Zoom | 16X |
| Flip | 0°/90°/180°/270° |
| Mirror | Off/On |
| Privacy Masking | 4 area, Off/On, rectangle |
| Audio Compression | AAC, G.711a, G.711Mu, G.726 |
| Audio Interface | Built-in Mic |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocols | ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPV4/V6, Multicast, NTP, PPPoE, QoS, RTP, RTSP, SMTP, TCP, UDP, UPnP, 802.1x, SNMP |
| Interoperability | CGI, ONVIF, PSIA |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 10 Users / 20 Users |
| Edge Storage | Local PC for instant recording, NAS, Micro SD Card 128GB |
| Web Viewer | Chrome, Firefox, IE, Safari |
| Management Software | DSS, Smart PSS, Easy4ip |
| Smart Phone Support | Android, iOS |
| Certifications | CE (EN 60950:2000), FCC: Part 15 Subpart B, UL60950-1 |
| Video Interface | N/A |
| RS485 | N/A |
| Alarm | N/A |
| Power Supply | DC12V, PoE (802.3af) (Class 0) |
| Power Consumption | < 5.5W |
| Operating Conditions | -30° C to +60° C (-22° F to +140° F) / Less than 95% RH |
| Storage Conditions | -30° C to +60° C (-22° F to +140° F) / Less than 95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | N/A |
| Casing | Metal |
| Dimensions | Φ106mm × 93.7mm (4.17” × 3.69”) |
| Net Weight | 0.47Kg (1.04lb) |
| Gross Weight | 0.65Kg (1.43lb) |
| Micro SD Slot | up to 128GB, Yes |
| Microphone | Yes |
| Power Supply Type | 12V and PoE |
| Shape | Turret (Dome) |
| Mounting Type | Outdoor |
