Networking / Wireless Access Points
SKU: AP3000
Cudy AP3000 is a business focused Wi-Fi 6 access point built to deliver fast, responsive wireless coverage in demanding indoor environments. Its low profile wall or ceiling mount design makes it well suited for offices, hotels, lecture halls, classrooms, and other shared spaces where stable coverage and clean installation matter.
With dual-band AX3000 wireless performance and a shielded 2.5 Gigabit Ethernet port, the AP3000 is designed to handle modern high speed networking needs while supporting many connected clients at once. Wi-Fi 6 technologies help improve efficiency, lower latency, and maintain smoother performance when users are streaming, browsing, or using real time applications across busy networks.
The AP3000 also offers flexible deployment options through support for PoE or DC power, multiple operating modes, mesh capability, and centralized management within the Cudy ecosystem. This makes it a practical choice for installers and network administrators who want strong wireless performance, scalable coverage, and straightforward integration into larger managed environments.
| Installation | Ceiling-mount, Wall-mount |
|---|---|
| Model Version | AP3000 1.0 |
| CPU | 1.3 GHz Dual-Core CPU |
| Flash/ROM | 256 MB (2 Gbit) NAND |
| DDR/RAM | 512 MB (4 Gbit) DDR4 |
| 5 GHz Wi-Fi Speed | 2402 Mbps |
| 2.4 GHz Wi-Fi Speed | 574 Mbps |
| 5 GHz Wi-Fi Streams | 3 Spatial Streams |
| 2.4 GHz Wi-Fi Streams | 2 Spatial Streams |
| Wi-Fi Antennas | 5× Internal |
| Range Performance | Max: 200 m (656 ft) |
| Wall Performance | one concrete wall with thickness < 20 cm (7'') or two concrete walls with thickness < 10 cm (4''), Two wooden walls with thickness < 10 cm (4'') |
| 2.5G RJ45 Ports | 1 |
| Ethernet Notes | Accepts PoE powering |
| LED | System |
| Physical Buttons | Reset Button |
| Power Input Type | DC Jack, PoE via Ethernet Port |
| Power Methods | 802.3at/af PoE, DC, Passive PoE |
| Power Input | DC: 12V 1.5A; Passive PoE: 48-57V; PoE: 802.3at/af |
| Power Adapter In the Box | AP3000: No adapter in the box |
| Max Power Consumption | 12 W (48 V PoE), 12 W (DC) |
| Idle Power Consumption | 6.1 W (48 V PoE), 6.1 W (DC) |
| Advanced Reliability | Hardware Watchdog |
| EMC | ESD: Contact: 4kV; Air: 8kV |
| Operating Temperature | -10 ℃ to 60 ℃ (14 ℉ to 140 ℉) |
| Storage Temperature | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉) |
| Operating Humidity | 10 to 90% non-condensing |
| Storage Humidity | 5% to 90% non-condensing |
| Certifications | CE, FCC |
| Dimensions | Φ231.9 × 57.1 mm |
| Product Weight | 489.6 g (17.27 oz.) |
| Wi-Fi Standards | Wi-Fi 6 |
| Max Wi-Fi Modulation | 1024-QAM |
| Wi-Fi Efficiency | BSS Color, MU-MIMO, OFDMA |
| Max Capacity | 256 |
| Recommended Client Upper Limit | 150 |
| Max Wi-Fi Channel Width | 160 MHz |
| Wi-Fi Security | WPA/WPA2/WPA3 |
| Multi-SSID | VLAN Support, 8 SSIDs, up to 4 SSIDs on each band |
| Operation Modes | Access Point, Client, Range Extender, Wi-Fi Router, WISP |
| Mesh | Cudy Mesh |
| Mesh Backhaul | Wired Backhaul, Wireless Backhaul |
| WAN Mode | DHCP, L2TP, PPPOE, PPTP, Static IP |
| Internet Failover Sequence | WAN, WISP |
| Multi-AP Management | Via Cudy AP Controller |
| All Devices Management | IP/MAC Binding, MAC Filter, Wi-Fi Time Schedule |
| Per-Devices Management | Device Rename, Internet On/Off, Online Time Schedule, VPN On/Off |
| Content Management | Domain Filter, IP Filter |
| QoS | Per-User Rate Limiting |
| 5 GHz FEM or PA/LNA | 3× External |
| 2.4 GHz FEM or PA/LNA | 2× External |
| Beamforming | Yes |
| Dimensions Inches | Φ9.13 × 2.25 inches |
| Package Content | Installation Guide, AP3000, Mounting Kit |
| Retail Package Weight | 850.9 g (30.01 oz.) |
| Retail Package Dimension | 283 × 238 × 68 mm |
| Retail Package Dimension (inches) | 11.14 × 9.37 × 2.68 inches |
| Units per Carton | 20 |
| Carton Net Weight | 17.0 kg (37.48 lbs) |
| Carton Gross Weight | 18.2 kg (40.12 lbs) |
| Carton Dimension | 58 × 37.5 × 49.5 cm |
| Compatible Products | C200P 1.0 |
| Compatible Accessories | POE200H 1.0, POE400H 1.0, POE48-18W 1.0, POE52-30W 1.0 |
| DHCP | Address Reservation, DHCP Client List, Server |
| IP Versions | IPv4/IPv6 |
| IPv6 Protocols | 464XLAT, DS-Lite, Dynamic (SLAAC/DHCPv6), MAP-E, Passthrough, Relay, Static (Fixed IP) |
| IPTV/VLAN | Tag VLAN |
| TTL Customization | Custom, Extend, Spoof |
| IGMP | IGMP Proxy, IGMP Snooping |
| Forwarding | DMZ, Port Forwarding, Port Triggering, UPnP |
| Firewall | Block PING, DoS Protection, SPI Firewall |
| Application Layer Gateway | FTP Passthrough, H323 Passthrough, IPSec Passthrough, L2TP Passthrough, PPTP Passthrough, RTSP Passthrough, SIP Passthrough, TFTP Passthrough |
| Captive Portal | Yes |
| VPN Server | IPsec, L2TP, OpenVPN, PPTP, WireGuard, Zerotier |
| VPN Client | IPsec, L2TP, OpenVPN, PPTP, WireGuard, Zerotier |
| DNS Options | DNS over TLS, Manual DNS, Override Clients' DNS, Rebind Protection |
| DNS over TLS Providers | Cloudflare, Custom, Google, Quad9 |
| Wake on LAN | Yes |
| Online Detection | Yes |
| LED Control | Yes |
| Local Control Method | App Control, Config Web Page |
| Remote Control Method | App Control, Config Page via HTTPS, TR069/TR098/TR111/TR143/TR181 |
| Firmware Upgrade | App (Over the Air), Local Update, Online Update |
| Reliability Tools | Backup and Restore, Timed Reboot |
| Diagnostic Tools | Diagnosis, NSLookup, Ping, System Log, Traceroute |
| Languages | Bengali, Catalan, Croatian, Czech, English, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Spanish, Dutch, Khmer, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Simplified Chinese, Slovak, Swedish, Thai, Turkish, Ukrainian, Vietnamese |
