SKU: FS1006P
Cudy FS1006P is a compact unmanaged PoE+ switch designed to simplify deployments for IP cameras, wireless access points, VoIP phones, and other powered network devices. Its six Fast Ethernet ports include four PoE+ ports for data and power delivery, plus two uplink ports for straightforward connection to the wider network.
This switch is built for reliable small network and surveillance installations. It combines a fanless metal enclosure with simple plug and play operation, making it suitable for offices, retail spaces, smart building projects, and home security setups where quiet operation and easy installation matter.
Practical network modes add flexibility for real world use. VLAN mode helps isolate ports for improved traffic separation, Extend mode supports longer cable runs for compatible deployments, and the built in watchdog function can automatically attempt to recover inactive PoE clients. The result is a straightforward switch that focuses on dependable PoE connectivity and easy day to day operation.
| Installation | Desktop, Wall-mount |
|---|---|
| RJ45 Ports | 6 x 10/100 Mbps RJ45 |
| PoE Ports | 4 x 10/100 Mbps RJ45 PoE, ports 1 to 4 |
| PoE Priority | Intelligent Power Management, automatically disconnects the lastly powered device when power exceeds budget |
| Extend Mode Ports | Ports 1 to 4 |
| VLAN Mode Ports | Ports 1 to 4 |
| LED Indicators | Link/ACT of each Ethernet port, Power |
| Physical Buttons | Default, Extend, VLAN DIP Switch |
| MAC Address Table | 2048 |
| Jumbo Frame | 2 KB |
| Packet Buffer | 768 Kbit |
| Power Input Type | AC Inlet |
| Power Methods | AC |
| Power Input | 100 to 240V, 50/60Hz |
| Max Power Excluding PoE | 1W |
| Grounding Methods | Grounding Point, Three-Prong Plug |
| Surge Protection | IEC/EN 61000-4-5, CM 4kV, Level 4 Surge, Power DM 2kV, RJ45 CM 4kV |
| Operating Temperature | 0 to 40 degrees C, 32 to 104 degrees F |
| Storage Temperature | -40 to 158 degrees F, -40 to 70 degrees C |
| Operating Humidity | 10 to 90% non-condensing |
| Storage Humidity | 10 to 95% non-condensing |
| Dimensions | 200 x 118 x 44 mm, 7.87 x 4.65 x 1.73 inches |
| Product Weight | 20.05 oz., 568.5 g |
| Casing Material | Metal |
| Package Contents | FS1006P, Installation Guide, Power Cord |
| Model | FS1006P 3.0 |
| Product Type | Unmanaged PoE+ switch |
| Total Ports | 6 |
| Uplink Ports | 2 x Fast Ethernet uplink ports |
| PoE Standard | IEEE 802.3af, IEEE 802.3at |
| PoE Mode | Mode A PoE |
| Max Power Per PoE Port | 30W |
| PoE Power Budget | 65W |
| Network Standards | IEEE 802.3af PoE, IEEE 802.3at PoE, IEEE 802.3i 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3x Flow Control |
| Watchdog Function | PoE watchdog will attempt to reboot inactive clients after 5 minutes |
| Max Copper Distance | 100 meters at 10 Mbps with Cat. 3 or higher |
| Max Copper Distance 100Mbps | 100 meters at 100 Mbps with Cat. 5 or higher |
| Extended Transmission Distance | 250 meters at 10 Mbps with Cat. 5e or higher, Extend Mode ports only |
| Switching Capacity | 1.2 Gbps |
| Forwarding Rate | 0.8928 Mpps |
| ESD Protection | Air 8kV, Contact 6kV, IEC/EN 61000-4-2, Level 3 ESD |
