SKU: SKU-046
Cudy R700 Gigabit Multi-WAN VPN Router is designed to act as a reliable gateway for small business, branch office, and advanced home networking environments. It focuses on keeping internet access stable by supporting multiple WAN connections, allowing traffic balancing across links or automatic backup when one connection fails.
The R700 also emphasizes secure remote connectivity with broad VPN support for server and client use. This makes it suitable for connecting offices, remote workers, and private network resources while maintaining flexible deployment options for different network setups.
Its compact metal housing and Gigabit wired interfaces make it a practical choice where dependable wired performance matters more than unnecessary complexity. It is built for users who need stronger control over routing, firewall behavior, and WAN management in a small, efficient form factor.
| Brand | Cudy |
|---|---|
| Model Version | R700 1.0 |
| CPU | 880 MHz Dual-Core |
| Flash/ROM | 16 MB (128 Mbit) NOR |
| DDR/RAM | 128 MB (1 Gbit) DDR3 |
| Gigabit RJ45 Ports | 5 |
| Ethernet Notes | 1× LAN Port, 1× WAN Port, 3× WAN/LAN Ports |
| LED | System, Power, Speed/Link/ACT of Ethernet Port |
| Physical Buttons | Reset Button |
| Power Input | DC Jack |
| Power Methods | DC |
| DC | 12V 1A |
| Power Adapter | 50/60 Hz AC, Input: 100 to 240 V, Output: 12V 1A DC |
| Operating Temperature | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Storage Temperature | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉) |
| Operating Humidity | 10 to 90% non-condensing |
| Storage Humidity | 5% to 90% non-condensing |
| Grounding Methods | Grounding Point |
| Certifications | CE, FCC, RoHS |
| Standards and Protocols | DHCP, DNS, HTTP, ICMP, IEEE 802.1q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IPSec, L2TP, NAT, OpenVPN, PPPoE, PPTP, TCP/IP, WireGuard, Zerotier |
| Interface | 1 Gigabit LAN port, 1 Gigabit WAN port, 3 Gigabit LAN/WAN ports |
| Network Media | 1000BASE-T: UTP category 5e, 100BASE-TX: UTP category 5, 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m), 5e cable (Max 100 m), 6 cable (Max 100 m), EIA/TIA-568 100Ω STP (Max 100 m) |
| Button | Reset Button |
| Power Supply | External 12V/1A DC Adapter |
| Flash | 16 MB NOR Flash |
| DRAM | 128 MB DDR |
| LED Indicators | LAN (Link/Act), PWR, SYS, WAN (Link/Act) |
| Dimensions (W x D x H) | 119 × 85 × 28 mm |
| IPSec VPN | 3DES, AES128, AES192, AES256 Encryption Algorithm, Aggressive Negotiation Mode, Dead Peer Detection (DPD), IKE v1/v2, Main, MD5, SHA1, SHA2, SHA254, SHA386, SHA512 Authentication Algorithm |
| PPTP VPN | PPTP VPN Client, PPTP VPN Server, PPTP with MPPE Encryption |
| L2TP VPN | L2TP Over IPSec, L2TP VPN Client, L2TP VPN Server |
| OpenVPN | OpenVPN Client, OpenVPN Server |
| Firewall | Block Ping from WAN, DoS, SPI |
| Filtering | Domain Filtering, IP Filtering, MAC Filtering |
| Static Routing | Supported |
| Policy Routing | Supported |
| Concurrent Session | 15, 360 |
| New Sessions / Second | 2, 600 |
| WAN Connection Type | Dynamic IP, PPPoE, Static IP |
| DHCP | DHCP Address Reservation, DHCP Server |
| MAC Clone | Modify WAN/LAN MAC Address |
| IPv6 | DS-Lite (Dual-stack), Dynamic (SLAAC/DHCPv6), MAP-E (Dual-stack), Passthrough, Relay, Static (Fixed IP) |
| Load Balance | Failover), Intelligent Load Balance, Link Backup (Timing, Online Detection |
| NAT | FTP/H.323/SIP/IPSec/PPTP ALG, NAT-DMZ, Port Triggering, UPnP, Virtual Server |
| Maintenance | Diagnostics (Ping and Traceroute and NSLookup), Export and Import Configuration, Remote Management, Syslog Support, Web Management Interface |
| Package Contents | Power Adapter, Quick Installation Guide, R700, RJ-45 Ethernet Cable |
| System Requirements | 2000, MAC OS, Microsoft Windows 98SE, NetWare, NT, UNIX or Linux, Vista, Windows 7/8/8.1/10, XP |
