SKU: SKU-065
The Dahua DH-IPC-HDW2431RP-ZS is a 4MP network CCTV camera designed for dependable day and night monitoring in a wide range of professional security installations.
Its motorized varifocal lens gives installers the flexibility to fine tune the viewing angle for entrances, walkways, yards, and general perimeter coverage, while the 4MP image output helps capture clear detail across the scene.
Dahua combines efficient H.265 and H.264 video compression with wide dynamic range and infrared illumination, helping the camera maintain usable footage in challenging lighting conditions and reducing storage demands on the recording system.
With PoE support, onboard microSD storage capability, and a weather resistant IP67 metal housing, this model is well suited to small and mid sized surveillance deployments that need practical installation flexibility and reliable around the clock operation.
| Model | DH-IPC-HDW2431RP-ZS |
|---|---|
| Product Type | IR Eyeball Network Camera |
| Image Sensor | 1/3” 4Megapixel progressive CMOS |
| Effective Pixels | 2688(H) x 1520(V) |
| RAM/ROM | 512MB/32MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | 1/3~1/100000s, Auto/Manual |
| Minimum Illumination | 30IRE, 0.03Lux/F1.4(Color, 0.3Lux/F1.4(Color, 0Lux/F1.4(IR on), 1/30s, 1/3s |
| S/N Ratio | More than 50dB |
| IR Distance | Up to 50m (164ft) |
| IR On/Off Control | Auto/Manual |
| IR LEDs | 2 |
| Lens Type | Motorized |
| Mount Type | Board-in |
| Focal Length | 2.7mm~13.5mm |
| Max. Aperture | F1.4 |
| Angle of View | H:104°~28°, V:55°~16° |
| Focus Control | Motorized |
| Close Focus Distance | 0.2m |
| DORI Distance Wide | Detect 64m, Identify 6m, Observe 26m, Recognize 13m |
| DORI Distance Tele | Detect 222m, Identify 22m, Observe 89m, Recognize 44m |
| Pan/Tilt/Rotation | Pan: 0°~360°, Rotation: 0°~360°, Tilt: 0°~78° |
| Event Trigger | Illegal access, IP address conflict, Motion detection, Network disconnection, Scene changing, Storage anomaly, Video tampering |
| IVS | Intrusion, Tripwire |
| Compression | H.265/H.264H/MJPEG(Sub Stream) |
| Smart Codec | H.265+/H.264+ |
| Streaming Capability | 2 Streams |
| Resolution | 1080P(1920×1080), 3M(2304×1296), 4M(2688x1520), 720P(1280×720), CIF(352×288/352×240), D1(704×576/704×480), VGA(640×480) |
| Frame Rate | 3M (1~25/30fps), Main Stream: 4M (1~20fps), Sub Stream: D1(1~20/25fps) |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264: 32K~10240Kbps, H.265: 12K~6400Kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| Backlight Compensation | BLC / HLC / WDR(120dB) |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control | Auto; Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off / On (4 Zone, Rectangle) |
| Region of Interest | Off / On (4 Zone) |
| Smart IR | Support |
| Digital Zoom | 16X |
| Flip | 0°/90°/180°/270° |
| Mirror | Off/On |
| Privacy Masking | rectangle, Off / On (4 Area |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocols | ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IEEE 802.1X, IGMP, IPV4/V6, Multicast, NTP, PPPoE, QoS, RTCP, RTP, RTSP, SMTP, TCP, TLS, UDP, UPnP |
| Interoperability | API, ONVIF Profile S&G |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 10 Users / 20 Users |
| Edge Storage | Local PC for instant recording, NAS, Micro SD Card 128GB |
| Web Viewer | Chrome, Firefox, IE, Safari |
| Management Software | DMSS, DSS, Smart PSS |
| Smart Phone | Android, iOS |
| Certifications | CE (EN 60950:2000), FCC: FCC Part 15 Subpart B, UL UL60950-1 |
| Video Interface | N/A |
| Audio Interface | N/A |
| RS485 | N/A |
| Alarm | N/A |
| Power Supply | DC12V, PoE (IEEE802.3af)(Class 0) |
| Power Consumption | <9.5W |
| Operating Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH |
| Storage Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | N/A |
| Casing | Metal |
| Dimensions | Φ122mm x 102mm (4.8 in x 4.0 in) |
| Net Weight | 0.60Kg (1.32lb) |
| Gross Weight | 0.71Kg (1.57lb) |
