CCTV Surveillance / Dahua / Full-color
SKU: DH-HAC-HFW1209CP-LED
DH-HAC-HFW1209CP-LED is a Dahua full color bullet camera designed for everyday perimeter and outdoor surveillance. It delivers 2MP video and uses full color starlight imaging to help maintain clearer scene detail in low light conditions.
This camera is built for flexible integration with existing analog HD systems, supporting multiple switchable video formats for broad recorder compatibility. Its compact bullet form factor and weather resistant construction make it a practical choice for entrances, walkways, small business exteriors, and residential monitoring.
Dahua positions this model as a dependable surveillance option for users who want visible color imaging at night, straightforward installation, and stable day to day performance in a wide range of environments.
| Image Sensor | 1/2.8 inch 2.16 Mega Pixels CMOS |
|---|---|
| Effective Pixels | 1920 (H)×1080 (V), 2MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25s to 1/100000s; NTSC: 1/30s to 1/100000s |
| Minimum Illumination | 0.005Lux/F1.6, 0Lux white light on, 30IRE |
| Fill Light On/Off Control | Auto; Manual |
| Fill Light Distance | Up to 20m (65.61ft) |
| Fill Light Number | 1 |
| Iris Type | Fixed iris |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 3.6mm |
| Max. Aperture | F1.6 |
| Angle of View | 3.6mm: 103.6° x 86.9° x 46.3° (diagonal x horizontal x vertical) |
| Close Focus Distance | 3.6mm: 1.2m (3.94ft) |
| BLC | BLC/HLC/WDR |
| Video Frame Rate | 720@25fps, 720@25fps; NTSC 1080@30fps, 720@30fps, 720@30fps. TVI: PAL 1080@25fps, 720@50fps; NTSC 1080@30fps, 720@60fps. AHD: PAL 1080@25fps, 720@60fps. CVBS: PAL 960×576H; NTSC 960×480H, CVI: PAL 1080@25fps |
| WDR | DWDR |
| White Balance | Auto; Manual |
| Gain Control | Auto; Manual |
| Noise Reduction | 2D NR |
| Smart Light | Yes |
| Digital Zoom | 16X |
| Mirror | Off/On |
| Privacy Masking | 4 area, Off/On, rectangle |
| Electronic Defog | Yes |
| Pan Range | 0° to 360° |
| Tilt Range | 0° to 78° |
| Rotation Range | 0° to 360° |
| Audio Interface | No Audio |
| Video Port | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Certifications | ANSI C63.4-2014); UL (UL60950-1+CAN/CSA C22.2 No.60950-1), CE EN55032, EN50130-4, EN55024, EN60950-1); FCC (CFR 47 FCC Part 15 subpartB |
| Power Supply | 12V ±30% DC |
| Power Consumption | Max 3W (12V DC, white light on) |
| Operating Temperature | -40°C to +60°C (-40°F to 140°F), <95% non-condensation |
| Storage Temperature | -40°C to +60°C (-40°F to 140°F), <95% non-condensation |
| Protection Grade | IP67 |
| Casing | Metal front cover + plastic main body + plastic bracket |
| Dimensions | 161.3 mm × 69.7 mm × 70.0 mm (6.35 in × 2.75 in × 2.75 in) |
| Net Weight | 0.20Kg (0.44lb) |
| Gross Weight | 0.28Kg (0.62lb) |
